HPE Aruba Networking JL261A 2930F 24G PoE+ 4SFP Switch
- Managed, Rack-mountable, 24 x 1G PoE+ ports, 4 x 1G SFP Uplinks, PoE+ (370W), Layer 3
[properties]
| Properties | HPE Aruba Networking 2930F 24G PoE+ 4SFP Switch (JL261A) |
| Description | Popular 28-port Gig access switch with 370 Watts PoE+ power. This model has 24x 10/100/1000 PoE+ ports and 4x 1000/100 SFP transceiver slots for uplink connectivity. |
| Product Family | 2930F Switch Series |
| Product Type | Ethernet Switch |
| I/O ports and slots | 24 RJ-45 autosensing 10/100/1000 PoE+ ports |
| 4 SFP uplink slots | |
| Additional ports and slots | 1x Out-of-band Ethernet management port 1x dual-personality (RJ-45 or USB micro-B) serial console port |
| Electrical characteristics | |
| Input Voltage | 100 - 127 / 200 - 240 VAC, rated |
| Maximum Heat Dissipation | 258 BTU/hr (272.2 kJ/hr) |
| Power Consumption (Maximum) | 445 W |
| PoE Power | 370 W PoE+ |
| Dimensions | 4.39 x 44.25 x 30.42 cm (1.73 x 17.42 x 11.98 in) |
| Weight | 8.6 lb (3.9 kg) |
[/properties]
[specifications]
| Specifications | 2930F-JL261A |
| Memory and processor | Dual Core ARM Cortex A9 @ 1016 MHz, 1 GB DDR3 SDRAM; Packet buffer size: 12.38 MB (4.5 MB Ingress/7.875 MB Egress), 4 GB eMMC |
| Performance | |
| 1000 Mb Latency | < 3.8 µs |
| Throughput | up to 41.7 Mpps |
| Switching capacity | 56 Gbps |
| Management |
HPE Aruba Networking Management Software (AirWave) Central Network Management IMC - Intelligent Management Center Command-line interface Web browser Configuration menu SNMP manager Telnet RMON1 FTP Out-of-band management (serial RS-232C or micro USB) |
[/specifications]
HPE Aruba 2930F 24G PoE+ 4SFP Switch (JL261A)
The HPE Aruba 2930F 24G PoE+ 4SFP Switch (JL261A) is a high-performance Layer 3 access switch built for modern digital workplaces. With 24 Gigabit PoE+ ports and 4 dedicated SFP uplinks, it delivers fast, reliable connectivity and up to 370W of PoE+ power to support wireless access points, IP phones, and security cameras. Featuring static and RIP routing, Access OSPF, robust QoS, and advanced security, the 2930F provides enterprise-grade performance without the need for additional software licensing. Designed for mobile-first and cloud-managed environments, it can be deployed quickly with Zero Touch Provisioning and managed via Aruba Central, AirWave, CLI, or Web GUI.
Key Features:
- 24 x Gigabit PoE+ Ports: Provides secure, high-speed connectivity and power with a total PoE budget of 370W.
- 4 x SFP Uplinks: Enables flexible fiber uplink options to the network core or distribution layer.
- Advanced Layer 3 Services: Supports RIP routing, Access OSPF, ACLs, and sFlow for optimized traffic control.
- Flexible Cloud & On-Premise Management: Manage via Aruba Central, AirWave, CLI, or Web GUI for full operational control.
- Enterprise-Grade Security & QoS: Includes 802.1X, ACLs, and policy-based traffic prioritization for critical applications.
Technical Overview:
- Model: JL261A
- Product Family: Aruba 2930F Switch Series
- Ports: 24 x 1G PoE+ RJ-45, 4 x 1G SFP uplinks
- PoE Budget: 370W (IEEE 802.3at PoE+)
- Switching Capacity: 56 Gbps
- Throughput: Up to 41.7 Mpps
- Processor & Memory: Dual Core ARM Cortex A9 @ 1016 MHz, 1 GB DDR3 SDRAM, 4 GB eMMC
- Packet Buffer: 12.38 MB (4.5 MB ingress / 7.875 MB egress)
- Latency: <3.8 µs (1G)
- Management: Aruba Central, AirWave, CLI, Web GUI, SNMP, Telnet, RMON1, FTP, out-of-band (RS-232C / micro-USB)
- Dimensions: 4.39 × 44.25 × 30.42 cm (1.73 × 17.42 × 11.98 in)
- Weight: 3.9 kg (8.6 lb)
- Power Consumption (Max): 445W
- Heat Dissipation: 258 BTU/hr
- Operating Temperature: 0°C to 45°C (32°F to 113°F)
Original: $955.00
-70%$955.00
$286.50Product Information
